Request a Quote
• Patent cutter technology
• 250mm/s high printing speed
• Three in one combo interface
• Provide OPOS driver
| Printing | Print Method | Direct Thermal |
| Resolution | 203 dpi (8 dots/mm) | |
| Print Speed | Max. 300mm/s | |
| Printing Width | Max. 72mm | |
| Interface | Standard | USB Type B, Cash Box |
| Option | Bluetooth, Wi-Fi, Ethernet, Serial Port, Paraller Port, Serial Port and Ethernet (2 in 1) | |
| Page Mode | Support | |
| Memory | RAM | 2 MB |
| Flash | 4 MB | |
| Fonts | Alphanumeric; Simplified Chinese, Traditional Chinese; 47 International Character Sets | |
| Barcode | 1D | UPC-A, UPC-E, EAN-8, EAN-13, CODE 39, ITF, CODEBAR, CODE 128, CODE 93 |
| 2D | PDF417, QR Code | |
| Graphics | Support bitmap printing with different density and user defined bitmap printing. (Max size of each bitmap is 40 KB, the total size of bitmap is 256 KB) | |
| Sensor | Standard | Paper out Detector, Paper near end Detector, Head up Detector |
| Option | Black Mark Detector | |
| LED Indicator | Power | Green |
| Paper | Red | |
| Error | Red | |
| Power Supply | Input | AC 100V-240V, 50/60Hz |
| Output | DC 24V, 2A | |
| Paper | Paper Type | Thermal Receipt Paper |
| Paper Width | Max. 82.5 mm | |
| Paper Thickness | 0.05 ~ 0.13 mm | |
| Roll Paper Diameter | Max. Φ83mm (O.D) | |
| Paper Load | Easy paper loading | |
| Paper cut | Partial cut | |
| Physical Characteristics | Operating | 0°C ~ 40°C, 20% ~ 85% R.H |
| Storage | -20°C ~ 70°C, 5% ~ 95% R.H | |
| Dimensions | 195(L)×145(W)×146(H) mm | |
| Weight | 1.8 kg | |
| Options Accessories | USB/Serial/Parallel Cable, Paper roll, Power Adapter, Power Cord, CD, Quick Start Guide | |
| Reliability | TPH life | 150 km |
| Cutter | 2 million cuts | |
| Software | Emulation | ESC/POS |
| Driver | Windows XP/ Vista/ 7/ 8/ 8.1/ 10 | |
| SDK | WinCE, WindowsMobile, Android | |
