Simple-to-Operate
- Full Color Interactive LCD
- Videos that Offer Valuable Information on the Printer Operation
- Intuitive Menu Navigation
- Tool Free Maintenance
Plug-and-Play
- LTDS (Label Tension Damper System)
- Flexible Media Support – Use Wound In or Wound Out Media
- High Energy Mode Prints on a Wide Variety of Stock Types
All-in-One
- Multiple Interfaces Auto Switching
- Competitive Emulations On-board
- Multi-national Language Support
| PRINT SPECIFICATIONS | |
| Method | Direct Thermal or Thermal Transfer |
| Resolution | 203 dpi (8 dots/mm), 305 dpi (12 dots/mm) , 609 dpi (24 dots/mm) |
| Speed | 10 ips (254.0 mm/sec), 8 ips (203.2 mm/sec), 6 ips (152.4 mm/sec) |
| Print Area | Maximum Width : 4.1″ (104.0 mm) Maximum Length (Continuous Mode): 98.43″ (2500.0 mm), 59.06″ (1500.0 mm) , 15.75″ (400.0 mm) |
| Mode | Continuous, Tear-off, Cutter, Dispense, Linerless |
| MEDIA SPECIFICATIONS | |
| Sensor Type | Adjustable Transmissive Sensor for Gap, Adjustable Reflective Sensor for Black Mark, Paper End, Ribbon Near-End/End |
| Media Type | Roll (Continuous, Die-cut, Linerless), Fan-fold, Tag, Ticket |
| Media | Width (With Liner) : 0.98″ (25.0 mm) – 5.15″ (131.0 mm) Minimum Length (With Liner) :Continuous 0.35″ (9 mm), Tear-off/Cutter 0.79″ (20 mm), Dispenser, 1.18″ (30 mm) Thickness (Label & Liner) : 0.002″ (0.060 mm) – 0.011″ (0.268 mm) Roll Diameter : Up to 8.6″ OD (220 mm) on 3″ (76.0 mm) ID Core Optional 10″ OD (254.0 mm) Wind :Face-in/Face-out, No Setting Change Required |
| Ribbon | Width : 1.55″ (39.5 mm) – 5.04″ (128.0 mm) Length : 1,968.5 ft (600 m) on 1″ (25.4 mm) ID Core Roll Diameter : Maximum 3.54″ (90.0 mm) Wind : Face-in/Face-out, No Setting Change Required SATO Genuine Consumables : For maximum print quality and optimum use, SATO recommends the use of SATO genuine consumables. |
| MEMORY & PROCESSING SPECIFICATIONS | |
| Dual CPU | CPU1: 2GB Flash, 256MB RAM CPU2: 4MB Flash, 64 MB RAM |
| USER FRIENDLY SUPPORT TOOLS | |
| Large Status LED | Blue/Red |
| Audible Alerts | Adjustable Volume Setting |
| Self Diagnosis | Head Check, Cutter-Cover Open,Stand-by Mode, Auto-Calibration |
| Display Panel | 3.5″ Full Color LCD |
| Tool-less Maintenance | Print Head Replacement and Adjustment, Platen Replacement |
| Multi-national Language Support | 47 Languages Scalable Fonts for Print 31 Languages for LCD Menu |
| Operation Video | Multiple Instructional Videos On-board (e.g. Error Resolution, Media Loading, Parts Replacement and Cleaning) |
| Emulation | Auto Detect – SBPL®, SZPL®, SDPL®, SIPL® or STCL® (Pre-installed), XML |
| Remote Maintenance | SNMP Ver. 3, HTTPS (Web Interface |
| COMMUNICATION INTERFACES SPECIFICATIONS | |
| Standard | USB 2.0 (Type A, Type B), Ethernet (IPv4/IPv6) on Rear Panel, USB 2.0 (Type A) on Front Panel, RS-232C, IEEE1284, EXT on Standard Interface Board, Bluetooth® Ver. 3.0 |
| Optional Wireless LAN Kit (Internal) | Wi-Fi®, Wi-Fi Direct® and CCX (Cisco®) Version 4 Certified, IEEE 802.11 a/b/g/n, Dual Band (2.4 GHz, 5 GHz) |
| OPTIONS | Cutter, Linerless Cutter Kit, Dispenser with Internal Liner Rewinder, Real-time Clock, UHF RFID (ISO18000-6 Type C), W-LAN Kit, External Rewinder (RWG-500) – Full 8″ OD Roll Take Up Note: Linerless and RFID available in CL4NX Model only. Dispenser option available in CL6NX Model only. |
| FONT SPECIFICATIONS | |
| Internal Fonts | 10 Bitmap SATO Fonts, 15 Scalable SATO Fonts, Multi-National Language Support (47 Languages/Unicode), Single and Double Byte Fonts (Korean, Chinese, Japanese) |
| BARCODE SYMBOLOGIES SPECIFICATIONS | |
| Barcodes | Linear : Code 39, Code 93, Code 128, CODABAR (NW7), EAN8/13, GS1-DatabarTM, GS1-128 (UCC/EAN128), Interleaved 2/5, Industrial 2/5, JAN 8/13, Matrix 2/5, MS1, Bookland, PostnetTM, UPC-A/E 2D Symbologies : PDF417, Micro PDF, Maxi Code, GS1 Data Matrix, QR Code, Micro QR Code and Composite Symbologies, Aztec User Downloadable Fonts, Graphics or Format :Maximum 100MB |
| OPERATING & ENVIRONMENT CHARACTERISTICS | |
| Electrical Requirements | Universal Auto-ranging Power Supply, 100-240VAC +/- 10%, 50/60Hz Energy Star – Compliant |
| Standards & Agency Approvals | IEC 60950, CE Marking, EN 60950-1, EN 55022 Class A, EN 55024, R&TTE, NEMKOGS, cMETus, UL60950-1/CSA C22.2 No. 60950-1, FCC 15 (SUB B, C), ICES-003, NMB003, BIS, C-Tick, RCM, CCC, SRRC, KC, S-Mark (Arg), SIRIM, IDA, PTQC, NBTC |
| Operation Environment | 32 to 104°F (0 to 40°C), 30-80% RH, Non-condensing; Linerless: 40 to 95°F (5 to 35°) 30 – 75% RH, Non-condensing |
| Storage Environment | -4 to 140°F (-20 to 60°C), 30 – 90% RH, Non-condensing |
| PHYSICAL CHARACTERISTICS | |
| Dimensions | Width: 10.66″ (271.0 mm) Depth: 17.99″ (457.0 mm) Height: 12.63″ (321.0 mm) |
| Construction | Die-cast Aluminum (Base, Frame, Front Cover, Ribbon Spindle, Print Head Mechanism) |
| Side-cover | Bi-fold for Space Saving with Large Clear Window |
| Secure Mounting | 3 Keyhole Slots on Chassis for Flat or Incline Setting |
| Weight | 33.0 lbs. (15.1kg) |
