- Unparalleled performance with 64-bit quad-core processor (1.3GHz)
- 4.7” HR display supporting water rejection and wet finger tracking
- Integrated superior 1D/2D barcode imager
- Great ergonomic scanning comfort;15° downwards scanner angle
- Advanced battery Cryogenics Circuit Design; provides 3x longer operating time when used below -20°C (compared to a traditional design battery)
- Easy Hot-swap battery design without downtime
- Support blazing-fast 4G/LTE and 2.4Ghz / 5Ghz wireless communication
- Wide range of professional accessories
- Zero shutter lag time: Speed up the picture taking process
- Device supported versatile MDM systems: SOTI,12Manage and MoboLink
Request a Quote
Operation System | |
CPU | 64-bits Quad Core 1.3GHz Processor |
Memory | 3GB RAM 16GB Flash Supports Micro SD (2GB to 32GB) |
OS | Android 6.0 |
Languages support | English, Simplified Chinese, Traditional Chinese, Japanese, Spanish, German, French, Italian, Portuguese, Korean and multiple languages |
Display | |
Gorilla Glass 3 with 5-point Capacitive Touch Panel | |
4.7” Color LCD 720×1280 High Resolution Display | |
Supporting water rejection, wet finger tracking & readable in sunlight | |
Keypad | |
4 Function Keys, Push-to-talk key, Volume up/down key, Left/right scan key, Power key. | |
Camera/Photos/Video | |
8MP Rear Camera | |
5MP Front Camera | |
LED flash light | |
Indicator | |
Vibrator | |
3 color LED to indicate charge, scan and message | |
Symbologies | |
1D CCD | UPC-A/E, EAN-8/13, Codabar, Code 39, Code 39 Full ASCI, Code 93, Code 32, Interleaved & Std. 2 of 5, EAN 128, Code 11, Delta, MSI/ Plessey, Code 128, Toshiba, RSS Expended, RSS Limited, RSS14. |
2D imager | PDF417, MicroPDF417, Composite, RSS, TLC-39, Datamatrix, QR Code, Micro QR Code, Aztec, MaxiCode, Postal Codes: US PostNet, US Planet, UK Postal, Australian Postal, Japan Postal Dutch Postal (KIX). |
RFID/HF | |
Frequency: | 13.56MHz |
Tag Support: | ISO15693, ISO14443A , ISO14443B Support NFC |
Communication | |
Interface | USB 2.0 w/ Pogo Pin |
USB | USB 2.0 |
WLAN | IEEE 802.11 a/b/g/n |
Bluetooth | Bluetooth 4.1 BLE supported |
WWAN 4G LTE | 2G – GSM: GSM850, EGSM900, DCS1800,PCS1900 3G – UMTS: B and 1, Band 2, Band 5, Band 8 4G –LTE: FDD Band 1(2100), Band 2(1900), Band 3(1800), Band 5(850), Band 7(2600), Band 8(900), Band 20(800) TDD: Band 38(2600), Band 39(1900), Band 40(2300), Band 41(2500) |
GPS | GPS/ GNSS/ BDS |
Other Sensors | Light, Proximity, eCompass, G-sensor |
Power Source (Hot Swappable) | |
Main battery | 3.6V 3120mAh Lithium-ion – Cryogenics Circuit Design battery. This battery provides 3x longer operating time when used below -20°C (compared to a traditional design battery) |
Extended battery | 3.6V 4660mAh |
Audio | |
1W Speaker 85 dB at 10cm | |
3.5mm Audio Jack | |
Receiver | |
Microphone | |
Expansion Slot | |
MicroSD | Support MicroSD memory card up to 32GB |
Enclosure | |
Weight | 287g (with standard battery) |
Dimension | 170 mm x 30.4 mm x 81.2 mm |
Environmental | |
Operating temperature | -20˚C to 50˚C |
Storage temperature | -30˚C to 60˚C |
Relative Humidity | 5% ~ 95% (non-condensing) |
Drop Specification | 1.8m |
Sealing | IP65 |
Vibration and Shock test | MIL-STD-810F, 514.4 Process II |
Accessories | |
4-slot Ethernet Cradle | |
4-slot Terminal Charging Cradle | |
1-Slot USB Cradle | |
1-Slot Ethernet Cradle | |
USB Holder Cable | |
Main Battery | |
Extended Battery | |
Vehicle cradle | |
(Visit http://eu.ute.com to discover our full range of accessories.) | |
Regulatory Approvals | |
CE, NCC, FCC, BSMI, VCCI, CCC, RoHS compliance |
