Ultra-lightweight device provides intuitive data entry and comfortable single-handed use in a stylish form factor.
Advanced integrated 802.11 a/b/g/n technology delivers real-time network access to critical information and supports advanced wireless security standards.
Supports both Microsoft® Windows® CE 6.0 and Windows Embedded Handheld 6.5 platforms.
Adaptus 6.0 imaging technology reads linear and 2D barcodes and captures digital images and electronic signatures — enabling workers to do more with a single device.
Constructed for use in light industrial in-premise environments.

MECHANICAL
Dimensions (L x W x H):
With Standard Battery: 175 mm x 69 mm x 39 mm (6.9 in x 2.7 in x 1.5 in)
With Extended Battery: 175 mm x 69 mm x 43 mm (6.9 in x 2.7 in x 1.7 in) – includes handstrap
At Grip: 58 mm (2.3 in)
Weight:
Imager: Standard Battery: 247 g (8.7 oz); Extended
Battery: 270 g (9.5 oz)
Laser: Standard Battery: 252 g (8.9 oz); Extended
Battery: 275 g (9.7 oz) – includes handstrap

ENVIRONMENTAL
Operating Temperature:
Imager: -10°C to 50°C (14°F to 122°F)
Laser: -10°C to 40°C (14°F to 104°F)
Storage Temperature: -20°C to 70°C (-4°F to 158°F)
Humidity: 95% humidity, non-condensing
Drop: Withstands multiple 1.2 m (4 ft) drops to concrete, all axis and across operating temperature range
Tumble: 500 1 m (3.3 ft) tumbles (1,000 impacts)
ESD: Air: ±15kV; Contact: ±8kV
Environmental Sealing: Independently certified to meet IP54 standards for moisture and particle resistance

SYSTEM ARCHITECTURE
Processor: Texas Instruments OMAP3715 800 MHz
Operating System: Microsoft Windows CE 6.0;Windows Embedded Handheld 6.5.3
Memory: 512 MB RAM; 512 MB Flash
Display: 7.1 cm (2.8 in) transmissive active matrix 65,000-color LCD with backlight, QVGA (240 x 320)
Keypad: 28-key shifted alphanumeric with backlit keys
Audio: Built-in microphone and speaker, stereo headset jack
I/O Ports: High-speed USB v2.0 (480 Mbps)
Voice Communication: Voice-over-IP and Push-to-Talk ready
Application Software: Honeywell Power Tools and Demos
Storage Expansion: User-accessible Micro SDHC memory card slot. Please check current price guide for available qualified card options
Battery: Standard: Li-Ion, 3.7V, 2200mAh;
Extended: Li-Ion, 3.7V, 3300mAh (includes extended battery door)
Expected Hours of Operation: 8+ hours (with scan and continuously transmitting)
Expected Charge Time:
Standard Battery: 4 hours
Extended Battery: 6 hours
Imager: Imager: 5603 (Laser Aimer), Standard Range (SR), High Density (HD); Adaptus 6.0 imaging technology; Laser: N4313 (only for WEH
6.5 version)
Decode Capabilities: Imager: Reads standard 1D and 2D symbologies; Laser: Reads standard 1D symbologies
Warranty: One-year for terminals and peripherals

WIRELESS CONNECTIVITY
WLAN: 802.11a/b/g/n, Wi-Fi™ certified
WLAN Security:Wi-Fi Alliance Certification, Wireless Security Supplicant (DeviceScape), 802.1x, WPA2, EAP, WEP, LEAP, TKIP, MD5, EAP-TLS, EAP-TTLS, WPAPSK, PEAP, CCXv4
WPAN:Bluetooth® Class II (10 m) v2.1 Enhanced Data Rate (EDR) with on-board antenna. BQB certified
