- An industry-leading platform: Qualcomm® Snapdragon™ 410 processor with 1.2 GHz quad-core CPU enables fast access to business- critical applications.
- Large, 12.7 cm(5 in) Corning Gorilla® capacitive touchscreen is readable both indoors and outdoors, and works when used with wet hands.
- Lightweight design offering the user the perfect combination of durability, comfort, convenience and portability. Small enough to fit conveniently into a pocket.
- Featuring smart battery technology, the ScanPal EDA50 device can power through a full shift and beyond.
- ScanPal EDA50 devices can be easily connected to multiple devices, enabling support for more use cases and applications.
Request a Quote
MECHANICAL | |
Dimension: | 153.5 mm x 78.9 mm x 18 mm (6.04 in x 3.11 in x 0.71 in) |
Weight: | 270 g (9.52 oz) |
Display Size: | 12.7 cm (5.0 in) |
Resolution: | 1280 x 720 High Definition |
Backlight: | LED |
Touchscreen: | Multi-touch capacitive |
Hard Keys: | Volume up/down key, left/right scan, power, reset |
Soft Keys: | Three touch keys (Back, Home, Menu) |
ENVIRONMENTAL | |
Operating Temperature: | -10°C to +50°C (+14°F to +122°F) |
Storage Temperature: | -20°C to +60°C (-4°F to +148°F) |
Humidity: | 10% to 90% (non-condensing) |
Drop: | Multiple 1.2 m (4 ft) drops to concrete under room temperature |
Tumble: | 200 times at 0.5 m (1.64 ft) |
ESD: | ±8 kV Direct; ±12 kV Air |
Environmental Sealing: | IP54 |
Vibration: | Vertical rms = 1.04 g, Transverse rms = 0.2 g, Longitudinal rms = 0.74 g |
SYSTEM ARCHITECTURE | |
Processor: | Qualcomm Snapdragon 410 MSM8916 1.2 GHz quad-core |
Memory: | 2 GB RAM, 8 GB Flash |
Operating System: | Android 7.1.1 with Google Mobile Services |
Default Language: | Worldwide English |
Storage Expansion: | MicroSDHC (up to 32 GB) |
Battery: | Li-Ion, 3.8 V, 4000 mAh |
Button Batteries: | 22 mF super-cap |
Real-Time Clock: | 10 min backup via super-cap |
Charging Time: | 4 hours |
Battery Runtime: | 12 hours |
Scan Notification: | Red/Green light |
Radio Co-Location: | All radios operate simultaneously |
Scan Engine: | HI2D Imager |
Camera: | 5.0-megapixel color camera with autofocus and LED flash |
LEDs: | Battery Condition: Red/Green/Blue Warranty: One-year factory warranty |
WIRELESS CONNECTIVITY | |
WLAN: | EEE 802.11 a/b/g/n radio NFC Bluetooth® Class 4.0 |
ACCESSORIES | |
Single Charging Cradle | |
Hand Strap | |
Replacement Battery | |
USB Communication Cable: | Micro USB 2.0 (communicates to PC, supports adaptor/USB charging) |
USB Wall Adaptor: | 5V/2A |
